Specification:

SPECIFICATIONS

• WARRANTY Two-year warranty, including Sensors and Battery
• CASE MATERIAL Impact-resistant polycarbonate alloys
• DIMENSIONS 29 x 29 x 55 cm (11.5 x 11.5 x 21.5 in)
• WEIGHT 7.5 kg (16.5 lb)
• POWER SOURCE/RUN TIME Rechargeable Nickel-Metal Hydride (NiMH) Battery 7 days (168 hours) typical @ 20 ºC, without Pump, with Wireless 3.5 days (84 hours) typical @ 20 ºC, with Pump, with Wireless 30 days (720 hours) typical @ 20 ºC, Electrochemical Sensors only, without Pump, with Wireless 8 hour recharge time
• ALARMS 108 decibel (dB) at 1 m (3.3 ft) redundant audible alarms Redundant, visual alarm LEDs (red and blue)
• DISPLAY/READOUT 11.2 cm (4.4 in) monochrome backlit graphical Liquid Crystal Display (LCD) KEYPAD Three buttons
• INGRESS PROTECTION IP66
• TEMPERATURE RANGE -20 °C to 55 °C (-4 °F to 131 °F)
• HUMIDITY RANGE 15% to 95% non-condensing (continuous)
• MEASURING RANGES

CATALYTIC BEAD

Combustible Gases: 0-100% LEL in 1% increments

ELECTROCHEMICAL

Ammonia (NH3): 0-500 ppm in 1 ppm increments

Carbon Monoxide (CO): 0-1,500 ppm in 1 ppm increments

Carbon Monoxide (CO High Range): 0-9,999 ppm in 1 ppm increments

Carbon Monoxide (CO/H2 Low): 0-1,000 ppm in 1 ppm increments

Carbon Monoxide/Hydrogen Sulfide: CO: 0-1,500 ppm in 1 ppm increments

H2S: 0-500 ppm in 0.1 ppm increments

Chlorine (Cl2): 0-50 ppm in 0.1 ppm increments

Hydrogen (H2): 0-2,000 ppm in 1 ppm increments

Hydrogen Sulfide (H2S): 0-500 ppm in 0.1 ppm increments

Hydrogen Cyanide (HCN): 0-30 ppm in 0.1 ppm increments

Nitrogen Dioxide (NO2): 0-150 ppm in 0.1 ppm increments

Oxygen (O2): 0-30% vol in 0.1% increments

Sulfur Dioxide (SO2): 0-150 ppm in 0.1 ppm increments

Phosphine (PH3): 0-5 ppm in 0.01 ppm increments

Nitric Oxide (NO): 0-1000 ppm in 1 ppm increments

Chlorine Dioxide (CLO2) 0-30 ppm in 0.1 ppm increments

Hydrogen Chloride (HCL) 0-30 ppm in 0.1 ppm increments

INFRARED

Carbon Dioxide (CO2): 0-5% vol in 0.01% increments

Hydrocarbon (HC) 0-100% LEL in 1% LEL increments

Methane (CH4) 0-100% LEL in 1% LEL increments

PHOTOIONIZATION VOC (10.6 eV): 0-2,000 ppm in 0.1 ppm increments

• EVENT LOGGING: 60 alarm events DATA LOG: At least 3 months at 10-second intervals
• PUMP: Optional integral pump, up to 30.48 m (100 ft) sample draw
• WIRELESS

Optional LENS Wireless, mesh network

Frequency: ISM license-free band (2.405 - 2.480 GHz)

Max Peers: 25 devices per network group / 10 independent, configurable network groups

Range: 300 m (~1,000 ft) line of sight

Encryption: AES-128

Approvals: FCC Part 15, IC, CE/RED, others **

SUPPLIED WITH MONITOR Calibration Cup (without Pump), Sample Tubing and Pump Inlet Water Barrier (with Pump), Hand Tool, Charging Power Supply and Region-Specific Cord

* These specifications are based on performance averages and may vary by instrument.

** See www.indsci.com/wireless-certifications for country-specific wireless approvals and certifications.
