Specification:

Standard G7 safety features

• Fall detection and No-motion detection: Tri-axis accelerometer, tri-axis gyro, software processing, configurable sensitivity, configurable time for no motion
• SOS latch: Pull latch to trigger SOS alert
• Silent SOS: Press and hold latch to trigger SOS alert
• Low-battery: Configurable threshold
• Worker check-in: Configurable timer (30 – 180 min, or off), automatic check-in when driving

Additional gas cartridge features

• Under limit
• Over limit
• Time-weighted average (TWA)
• Short-term exposure limit (STEL)
• High gas alert
• Low gas alert
• Bump test and calibration notification
• Bump test and calibration failure

Size & weight

G7 with Standard Cartridge

• Size: 64 mm x 124 mm x 27 mm (2.5” x 4.9” x 1.1”)
• Weight: 162 g (5.7 oz)

G7 with Single-gas Cartridge

• Size: 64 mm x 128 mm x 27 mm (2.5” x 5.0” x 1.1”)
• Weight: 167 g (5.9 oz)

G7 with Multi-gas diffusion Cartridge

• Size: 66 mm x 150 mm x 27 mm (2.5” x 5.9” x 1.1”)
• Weight: 192 g (6.8 oz)

G7 with Multi-gas pump Cartridge

• Size: 66 mm x 151 mm x 38.5 mm (2.6” x 5.95” x 1.52”)
• Weight: 238 g (8.4 oz)

User interface

168 by 144 pixel graphical, high contrast, liquid crystal display with front lighting, menu system driven by three-button keypad, power button (on/off), check-in button (check-in/silent SOS), SOS latch (send emergency alert)

Multi-language support: Yes, EN, FR, ES, DE, IT, NL, PT

User notification

• Green SureSafe® light: Blinking (powered), continuous (connected)
• Yellow top and front lights: Yellow pending alarm and yellow warning alarm
• Red top and front lights: Red alert communicated
• Blue LiveResponse™ top and front lights: Confirmation that a monitoring team has acknowledged the alert
• Alarm Indicators: Speaker, LED lights and vibration motor
• Speaker sound pressure level: ~95 dB @ 30 cm (~95 dB @ 11.8”)
• Voice calling: Speakerphone and phone modes (G7c model only)

G7c wireless radio

• Wireless coverage: 100 countries, 200 wireless carriers
• North America: 2G/3G radio, GSM 850 MHz, PCS 1900 MHz, 3G UMTS bands 2, 5 and 6
• International: 2G/3G radio, E-GSM 900 MHz, DSC 1800 MHz, 3G UMTS bands 1 and 8
• Antenna: Internal regionally optimized

Location technology

• GPS Radio: 48-channel high sensitivity
• Assisted-GPS: Yes (G7c model only)
• GPS Accuracy: ~5 m (16 ft) Outdoors
• Indoor location technology: Blackline Safety location beacons
• Location update frequency: G7c 5 min, G7x 15 min defaults

Power & battery

• Rechargeable Li-ion battery: 1100 mAh Li-ion Battery Life: 18 hours at 20°C (68°F) under normal usage
• Charge time: 4 hours

Environmental

• Storage temperature: -30°C to 60°C (-22°F to 140°F)
• Operating temperature: -20°C to 55°C (-4°F to 131°F)
• Charging temperature: 0°C to 45°C (32°F to 113°F)
• Ingress Protection: Designed to meet IP67

Approvals

• G7c: SAR, RoHS, CE, RCM
• Unit ID: 3567xxxxxx
• FCC ID: W77G7C IC: 8255A-G7C Contains FCC ID: XPY1CGM5NNN, IC: 8595A-1CGM5NNN

or

• Unit ID: 3566xxxxxx Contains FCC ID: XPY1CGM5NNN, IC: 8595A-1CGM5NNN
• Canada & USA: Class I Division 1 Group A,B,C,D T4; Class I Zone 0 AEx da ia IIC T4; Ex da ia IIC T4 Ga
• IECEx: Ex da ia IIC T4 Ga
• ATEX: Ex da ia IIC T4 Ga
• LEL: CSA C22.2 No.152; ISA 12.13.01
• LEL Pump Cartridge: CSA C22.2 No.152; 0°C ≤ Ta ≤ 40°C; ANSI/ISA-12.13.01; -10°C ≤ Ta ≤ 40°C

Warranty

• G7: two years limited warranty
• Cartridges: lifetime with service plan
• Blackline Complete: three year operating lease with three year warranty

Blackline Live web application

Cloud-hosted safety monitoring web application is highly customizable for every customer requirement. Includes live map, employee address book, user roles, alert management, device configurations, alert setups and reporting.
